Wholesale Japan PSE 3 Pins JIS C 8303 Plug To IEC 60320 C19 Connector, Japan Power Supply Cords

Japan PSE 3 Pins JIS C 8303 Plug To IEC 60320 C19 Connector, Japan Power Supply Cords

Plug and Connector Type: B, C19
Japan PSE 3 pins JIS C 8303 plug to IEC 60320 C19 Connector, Japan Power Supply Cords with PSE Certified List.
Built to Japan JIS C 8303, IEC 60320 C19 standards.
Rated up to 7A, 12A, 15A 125V.

Our Japan PSE 3 pins JIS C 8303 Plug to IEC 60320 C19 Connector, Japan Power Supply Cords products are fully molded with a low profile ergonomic design and RoHS, REACH, and PAHS compliant.

get a quote
  • LABEL

    VALUE

    Connector Standard

    Janpan JIS C 8303, IEC 60320 C19

    Maximum Current rating

    7A, 12A, 15A

    Maximum Voltage

    125V

    Number of Poles and Wires

    3 poles, 3 wires

    Copper Conductor Material

    Oxygen-free Copper (OFCU)

    Outer Jacket Material

    PVC, Rubber, Halogen-Free, Textile braid

    Blade Material

    Nickel coated Brass

    Flammability Rating

    UL 94V-0

    Color

    Black is standard but any color available

    Temperature Rating

    Minus 40C though plus 75C

    Approvals

    PSE

    Environmental Certifications

    RoHS, REACH, PAHs

    Testing

    Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity

    Country of Origin

    Made In China

    Packing

    Standard Export Carton
